	AKA (Label): X61-9857-02, 88-3262, Product number (P/N): X61985702 (X61-9857-02), Keywords/Tags: X61985702 (X61-9857-02) \| 883262 (88-3262) Date of intro: ~1972, Classification: / Part / PCB, Main Components: HITACHI: HD32107P; HITACHI: HD32108P; HITACHI: HD32109P; HITACHI: HD32112P; HITACHI: HD32151P, Other components: HITACHI: FD1018; HITACHI: FD1021; HITACHI: HD3280P; TEXAS INSTRUMENTS: SN75491N {2x}; TEXAS INSTRUMENTS: SN75492N {3x}, Courtesy of: KOGGE Udo, Used in: CANON: MP1212
Item

AKA (Label): X61-9857-02, 88-3262, Product number (P/N): X61985702 (X61-9857-02),
Keywords/Tags: X61985702 (X61-9857-02) | 883262 (88-3262)
Date of intro: ~1972,
Classification: / Part / PCB,
Main Components: HITACHI: HD32107P; HITACHI: HD32108P; HITACHI: HD32109P; HITACHI: HD32112P; HITACHI: HD32151P,
Other components: HITACHI: FD1018; HITACHI: FD1021; HITACHI: HD3280P; TEXAS INSTRUMENTS: SN75491N {2x}; TEXAS INSTRUMENTS: SN75492N {3x},
Courtesy of: KOGGE Udo,
Used in: CANON: MP1212
