SHARP: EL808
(Page 1/1)


AKA: LC LIQUID CRYSTAL, EL-808, AKA (Label): MODEL EL-808, Product number (P/N): EL808 (EL-808),
Keywords/Tags: EL808 (EL-808) | 808 | LC LIQUID CRYSTAL
Date of intro: 1973, Origin: Japan (List), Dimensions: 178x102x42mm, Weight: 350g,
Power: 6V: (AA x4) + Adaptor, Adaptor: SHARP_adaptors: EL97,
Display: Type = Display (LCD reverse) (List), Digits = 8+1,
Number of keys: 17, #Key-Black: 17,
Classification: / Desktop with Display,
Related with: SHARP_docu: (Instr.) EL808; SHARP_docu: (Support addresses) 40513L; SHARP_docu: (Broch.) *: COMPET; SHARP_docu: (Ad.) *: Who creates the world's most complete...,
Main Components: NEC: µPD224C,
Known Serial-numbers: 3015600 | 342566Y | 347077X | 355377X | 4076534 | 4460221 (List of all S/Ns from SHARP)
Initial Cost Price: 24800 JPY (€ 200,88), Collector value: 8/10,
Courtesy of: CALCUSEUM (Serge DEVIDTS),
Internet: Link-1: DATAMATH CALCULATOR MUSEUM, Link-2: Robert LACOSTE, Link-3: SCHLEPPTOPS Rechnerwiki

Item

Rear / Battery compartment

Perspective, profile view
(Courtesy of: FROICU Romeo)

Accessories

Internals
(Courtesy of: FROICU Romeo)

Internals (display)
(Courtesy of: FROICU Romeo)

Internals (PCB)
(Courtesy of: FROICU Romeo)
F1139

Guarantee, warranty
(J)
Pag.1/2

Guarantee, warranty
(J)
Pag.2/2

Label, name plate / Bottom
S/N: 4076534

Protection (pouche)
